4683-TTM-3F | Johnson Controls | Network & Wireless

N2 REPEATER 24V

Brand:Johnson Controls

MPN:4683-TTM-3F

SKU:4683-TTM-3F

List Price:

$1,796.00

Today's Price:

$933.92

Lead time of > 15 days. Chat with Kele experts now

product specifications

Type

RS-485 to RS-485

Display

Operating Temperature Range

-25 to 70 °C, 13 to 158 °F

Supply Voltage (Nominal)

24 VAC

product series specifications

Operating Temp. Range: -25 to 70° C |-13 to 158° F

Storage Temp. Range: -25 to +85° C |-13 to 185° F

Relative Humidity (RH): 10 to 95% RH (noncondensing) - up to 40° C (104° F).

Power Line Fuse: 0.5A|125V|0.75A|3AG type

Wire Range: 14 to 26 AWG.

Duplex: Half duplex only

Shipping Weight: 3.0 pounds (1.4 kg) packed per unit

Baud Rates: 600|1200|2400|4800|9600|19.2K|38.4K|76.8K baud rates. Note: Switch must be in the proper baud rate position for proper operation.

product series features

Designed for use with Johnson Controls N2 or BACnet bus
Drives up to (32) RS-485 devices
LED indicates transmission direction, RS-485 buds fault conditions and power applied
Isolates & boosts signal up to 4000 ft.
Baud rates of 600, 1200, 2400, 4800, 9600, 19.2K, 38.4K, and 76.8K are switch selectable
Field-selectable end-of-line network terminations on both A and B sides

more information & related documents

Series Description

The N2 Network Repeater device allows users to take full advantage of the RS-485 standard’s extended communication distances and multi-dropping capabilities. In addition, these devices offer field selectable End-of-Line Network (EOLN) terminations on both the A and B networks.<br> <br>

Kele Description

N2 REPEATER 24V

Manufacturer

Johnson Controls
