PSM30SA | Johnson Controls | Thermostats & Controllers

T-STAT/1HEAT,MECHANICAL

Brand:Johnson Controls

MPN:PSM30SA

SKU:PSM30SA

List Price:

$58.58

Today's Price:

$30.46



20 in stock

product specifications

Type

Wall

Stages

Two Stage

System Switching

Yes

Fan Switching

Yes

product series specifications

Electrical Ratings: 24 VAC (30 VAC maximum)

Anticipator Rating: 0.15 A to 1.2 A

Temperature Control Range: 45°F to 90°F (7° to 32°C). Accuracy ±1°F over a range of 50°F to 95°F

Environmental Limits: Moisture and dust meets IP20; Operating humidity 20% to 90% noncondensing; Operating temperature +32°F to +95°F (+0°C to +35°C); Storage temperature -4°F to +130°F (-20°C to +54°C); Electrical immunity meets relevant CE specifications

Compatible With: Most 24V gas, oil, electric heating systems;2 wire hydronic systems; Millivolt systems; Hydronic air handlers; Single-stage heat pumps

Not Compatible With: 3 wire hydronic systems; multi-stage heat pumps;120V/240V systems

Physical Dimensions (When mounted): Width = 3" (77 mm); Height = 3.50" (90 mm); Depth = 1.25" (32 mm); Optional wall plate Part no. MTO84S, 4.75" (121 mm) X4.75" (121 mm)

Packaging: Packaged in box - carton quantity = 50; Carton specifications 16.50" long X 14.75" wide X 12.375"deep. Carton weight 17 lbs.

UPC Code: 0 21079 98030 7

Warranty: 5 years

product series features

  • Clean, attractive design
  • Snap action mechanism
  • Value priced
  • Adjustable heat anticipator
  • Contains no mercury

more information & related documents

Series Description

The LUX PSM Series are conventional snap action mechanical thermostats with no digital displays. The PMS30SA is a heat only, and the PSM40SA is a heating/cooling 24V thermostat that works with most 24V gas, oil, electric systems, 2-wire hydronic systems, millivolt systems, hydronic air handlers, and single-stage heat pumps. The PSM400SA is a standard horizontal wall mount mechanical thermostat that will work with 1H/1C systems as well. (the PSM400SA is heated only for hydronic systems)

Kele Description

T-STAT/1HEAT,MECHANICAL

Manufacturer

Johnson Controls
