Supply Voltage: 24-277 VAC @ 1 VA ±10% 50/60 Hz

Setpoint: 50° to 90°F (10° to 32°C) adjustable

Sensor Type: Built-in 10K thermistor Type II

Remote Sensor: 10K thermistor Type II, acc. required

Output Control: 6-SPST relays, H/C/Damper, Fan-L/M/H

Output Amps: See catalog page

Control: Proportional plus Integral (PI)

Dead-band: 3°F (1.6°C)

Setpoint: 55° to 90°F (10° to 32°C)

Setback (H/C): 55° to 90°F (13° to 32°C), adjustable 8‚°F (4.4°C) minimum separation

Keypad Lockout: All buttons disabled except setpoint

Display: 1" x 1.5" backlit digital display room temp., setpoint, system and fan status

Display Offset: ±9‚°F (5‚°C), in 1‚°F (0.5‚°C) increments

Button Controls:

Up, Down: Temperature select

System: Heat/Cool/Auto/Off

Fan Control: On/Off/Auto

Fan Speed: Hi/Medium/Low, hold for °F/°C

Adjustments: Service menu set up, 9 parameters

Switch Cycles: 100,000 cycles

Termination: 6" flying leads 18-14 AWG

Color: White

Mounting: Horizontal on wall. Screw direct or 4" x 4" back box

Operating Temperature: 130°F (54°C) Maximum

Operating Humidity: 98% RH non-condensing

Enclosure Rating: NEMA 1, Vinyl plastic

Dimensions: 4.4" H x 5.8" W x 1.4" D (11.2 x 14.7 x 3.5 cm)

Weight: 0.7 lb. (0.32 Kg)

Approvals: UL File# E50023 and ADA compliant

Warranty: 5 years
