Supply Voltage:8 to 30VDC @ 25 mA max

Accuracy: ±0.5% of span

Pressure Range:± 1% of span for =50 psig

Signal Output (Current): 4-20 mA @ 800 O (loop powered)

Sensor Type: ASIC piezo-resistive and temp. Compensated

Display: (Optional) 2½ Dial gauge or 0.5? Digital with 3.5 digits

Overpressure: (Burst) 3x rated pressure

Max Operating Pressure: (Proof) 5x rated pressure

Operating Temperature: -40° to 221°F (-40° to 105°C)

Operating Humidity:10 to 90% Non-condensing

Wetted Parts: Brass, 304SS and 316SS

Media Compatibility: Liquid or Gas compatible w/Brass, 304SS and 316SS

Process Connection: Direct-1/8? MNPT, Encl. bulkhead- 1/8? FNPT

Wiring Terminations: 2-16 AWG pigtail in 36? (91cm) cable

Mounting: By process connection or optional enclosure

Enclosure Rating: (Optional) plastic enclosure, NEMA 4, (IP66)

Dimensions: 5.11?H x 5.11?W x 2.95?D, (13.0 x 13.0 x 7.5 cm)

Weight: 0.3 lb (0.13 Kg)

Warranty: 1 year
