Supply Voltage: 10 to 30 VDC @ 38 mA max.

Accuracy: ±0.25% span FS (includes linearity, repeatability and Hysteresis)

Sensor Type: Piezoresistive

Normal Measurement Range: Vacuum to 8000 PSIG (See ordering)

Overpressure (Burst): 1000 to 12,000 PSIG (See ordering)

Max Operating Pressure (Proof): 400 to 10,000 PSIG (See ordering)

Operating Temperature: 0° to 200°C (-18° to 93°F)

Compensated Temperature Range: 0° to 175°C (-18° to 79°F)

Operating Humidity: 5 to 95% Non-condensing

Wetted Parts: 316L Stainless Steel

Media Compatibility: Liquid or Gas compatible w/316 SS

Process Connection: 1/4" male or female NPT or BSPT

Wiring Terminations: 2 wire pigtails with 3', 6', or 9' cable

OR: 2 terminals for M12 or DIN plug

Mounting: Mount in any position

Enclosure Rating: NEMA 4X, IP66

Dimensions:

-GH: 3.2"L x 1" Dia (8.1 x 2.5 cm)

-CG: 5.5"L x 1.28"W x 3.5"D (13.9 x 3.25 x 8.9 cm)

Weight: 0.6 lb (0.3 Kg)

Approvals: CE, NSF, UL

Warranty: 1 year
