Input Power: Class 2; 12 to 24 Vdc, loop-powered (polarity insensitive)

Maximum Current Draw: 29 mA

Output: 2-wire transmitter; user-selectable 4 to 20 mA (clipped & capped)

Surge Damping: Electronic; 5-second averaging

Zero Adjust: Pushbutton auto-zero terminals

Housing Material: White powder-coated aluminum

0 to 50 psi (0 to 3.45 barg)(Gauge): 0-5/10/25/50 psid (0-0.34/0.69/1.72/3.45 bard)(Differential)

0 to 100 psig (0 to 6.89barg) (Gauge): 0-10/20/50/100 psid (Differential)(0-0.69/1.38/3.45/6.89 bard) (Differential)

0 to 250 psi (0 to 17.24 bar)(Gauge): 0-25/50/125/250 psid (Differential)(0-1.72/3.45/8.62/17.24 bard) (Differential)

Accuracy @ 25°C: Range A, B, C: ±1% F.S.; Range D: ±2% F.S.

Media Compatibility: Media compatible with 17-4 PH stainless steel

Long Term Stability: ±0.25% per year

Proof Pressure: Max. 2x F.S. range

Burst Pressure: Max. 5x F.S. range

TemperatureCompensated Range: 0 to 50 °C (32 to 122 °F); TC Zero <±1.5% of product F.S. per sensor; TC Span<±1.5% of product F.S. per sensor, (2 sensors per unit)

Media Temperature Limits: -20 to 85°C (-4 to 185°F); 0 to 90% RH non-condensing

Product Operating Environment: -10 to 55°C (14 to 130 °F); 0 to 90% RH non-condensing

Limited Warranty: 5 years
