9833914 | Wika Instrument Corporation | Pressure Components
Dial Gauge, Analog, ±0.50%, 30" Hg Vacuum, 4.50" Dial, 1/2" NPT, Wet, Lower Mount
Brand:Wika Instrument Corporation
MPN:9833914
SKU:9833914
List Price:
$422.00
Today's Price:
$219.44
Log in for customized pricingproduct specifications
Body Material
Plastic
Direction
Uni-Directional
Measurement
PSI
Media Compatibility
Liquid,Gas
Process Connection
1/2 in NPTM bottom
Range
±1 psi
Connection
1/2 in NPT
Accuracy
0.5%,1.0 % span
Measurement Range
30 in Hg0
Dial Size
4.5 in
Filling
Wet
Wetted Materials
Stainless Steel
Application
Hydraulic and Pneumatic Systems,Pumps, Compressors, Water Systems, Regulators
Mount
Lower Back
Gauge Dial
Aluminum
Gauge Is LF
true
product series specifications
Supply Voltage (If Used): Not Required
Readout (Analog, digital etc.): Black tip needle with white background
Dial (white, mirrored, LCD, LED, Stop pins Etc.): Round dial w/ graduations (PSI/kPa) per order
Window Material, (Glass, Polycarbonate etc.): Clear plastic
Indication: Scale Selectable by order
Accuracy: Left dial ±3%, Center dial ±2%, right dial ±3%, @ 68°F (20°C)
Sensor principle (Balanced, Bourdon tube, Capacitive) : Bourdon tube
Operating Pressure Ranges: 30" Hg vacuum to 5000 psi
Overpressure (Burst): 800 psi (5517 kPa),(>800 psi at gauge value)
Max Operating Pressure (Proof): Full Scale per order
Operating Temperature: -40° to 140°F (-40° to 60°C)
Media Temperature: max 140°F (60°C)
Operating Humidity: 0 to 95% Non-condensing
Wetted Parts: Brass and Copper alloy
Media Compatibility: Water, Glycol, and Inert Dry Air
Process Connection: Brass NPT threads
111.10: Lower Mount (LM), 1/8" or ¼" MNPT
111.12: Center Back Mount (CBM), 1/8" or ¼" MNPT
Mounting: Process connection or U-clamp
Wiring Terminations (if needed): None required
Enclosure Case Rating: Plastic or steel housing w/Clear face
Enclosure Rating: NEMA 1
Dimensions : Dial Diameter 1.5", 2.0", 2.5", 4.0" per order
Weight: Not given
Approvals: RoHS, UL File SA6444
Warranty: 1 Year
product series features
- Copper alloy wetted parts
- Black ABS or painted steel case
- Cost effective design
- Pressure ranges from 30 in Hg vacuum to 6000 psig
- Available in 1-1/2 in through 4 in sizes
more information & related documents
Series Description
Designed for long, reliable service under rugged conditions, the WIKA 111.10 pressure gauge is typically used in applications where the media does not corrode brass. This low cost pressure gauge with lower mount connection features a black ABS or painted steel case standard, and a coiled safety Bourdon tube for 800 psig and higher.
Kele Description
DIAL GAUGE, ANALOG, +/-0.50%, 30" HG VACUUM-0, 4.50" DIAL, 1/2" NPT, WET, LWR MOUNT
Manufacturer
Wika Instrument Corporation
Related Documents
111.10 Series Spec Sheet
