SDN-40-24-480C | Kele | Power Supplies
SDN-C Series Compact DIN Rail Power Supply, Nominal Output Current: 40 A (960 W), Nominal Voltage Input: 380/480 Vac, Nominal Voltage Output: 24 V, Frequency 50/60 Hz, Three Phase
Brand:Kele
MPN:SDN-40-24-480C
SKU:SDN 40-24-480C
List Price:
$4,027.00
Today's Price:
$2,094.04
Log in for customized pricingproduct specifications
Mount
DIN rail
Output Voltage
24 VAC
Primary Voltage
480 VAC
Type
Enclosed Power Supply
Primary Voltage Input
480 VAC
DC Voltage Output Type
Fixed
DC Voltage Output Range
24 VDC
DC Current Output
40 Amps
product series specifications
Supply Voltage:
Single Phase: 115/230 VAC
Three Phase: 380-480 VAC
Output Voltage: 24 VDC
Frequency:
Single Phase: 43-67 Hz
Three Phase: 50-60 Hz
Output Current:
SDN 5-24: 120W, 5A @ 24VDC
SDN 10-24: 240W, 10A @ 24VDC
SDN 20-24: 480W, 20A @ 24VDC
SDN 40-24: 960W, 40A @ 24VDC
Fusing:
Single Phase: Internally fused
Three Phase: Externally fused
LED: Green, Yellow, Red
Connections: Terminals accepting 12-16 AWG wire
Mounting: Din Rail
Operating Temperature: -13° to 140°F (-25° to 60°C)
Operating Humidity: < 90% RH, non-condensing
Approvals: CE, UL File #E234790, SEMI F47, RoHS
Warranty: 5 years
product series features
- Compact packaging to save space on the DIN rail
- Visual diagnostic LEDs for input and output status at a glance
- High efficiency saves energy and lowers amount of heat generated in panel
- PowerBoost™ overload capability to start high inrush loads
more information & related documents
Series Description
The Sola/Hevi-Duty SDN-C Compact Series DIN rail series power supplies are the next generation of the SDN Series. These models combine high efficiency and compact size with new visual diagnostic LEDs to offer the most performance available from SolaHD. These have a patented DIN rail mounting clip and large, rugged accessible screw terminals.
Kele Description
40A (960W) 24V 480VAC INPUT 3PH DIN P/S
Manufacturer
Kele
SDN-C Datasheet
