* product series image displayed

NWAQL-OB | IDEC | Panel Fabrication

PLATE BLANK CUSTOM LEGEND 22MM

Brand:IDEC

MPN:NWAQL-OB

SKU:NWAQL-OB

List Price:

$5.28

Today's Price:

$2.75

3 in stock

product series specifications

Contact Rating: 10A, 600 VAC/VDC max.; 5 mA, 3 VAC/VDC minimum

Contact Resistance: 50 mO maximum (initial value)

Contact Material: Silver

Electrical Life: 500,000 minimum operations

Protection Rating: NEMA 1, 2, 3, 3R, 4, 4X, 12, 13, IP65

Applicable Wire Size: Minimum 1 x 22 AWG, Maximum 2 x 14 AWG or 1 x 12 AWG

Mechanical Life: 500,000 minimum operations

Mounting: 0.878" (2.23 cm) hole

Panel Thickness: Panel thickness adjustment ring, 0.04" to 0.24" (0.10 to 0.61 cm)

Approvals: UL File #E68961; CSA File #LR48366, CE, RoHS

Warranty: 1 year

product series features

Rugged, oil-tight construction
Snap-fit blocks with N.O. and N.C. contacts
Self-cleaning silver contacts
Durable nylon operator base
Optional key or lever styles available

more information & related documents

Series Description

The IDEC ASW Series selector switches are general purpose selector switches for pilot duty control of electrical equipment, such as fans, pumps, compressors, or control circuits. Each selector switch has been proven to perform in high-demand applications for HVAC and building automation systems. Rely on these switches for fan control, pump control and compressor control. If a project requires multiple panels configured in the same way, consider using Kele's Custom Panel Shop. Experienced panel technicians will assemble the panels according to specifications and drawings. Then, panels are shipped to a desired location. The information is saved so additional panels can be easily ordered on demand. Stop spending time on panel fabrication and let the experts do it.

Kele Description

PLATE BLANK CUSTOM LEGEND 22MM

Manufacturer

IDEC
