CIRCUIT BREAKER, MINIATURE, 1P, C CURVE, 3A, 277 VAC
Brand:Noark
MPN:B1H1C3
SKU:B1H1C3
List Price:
$35.00
Today's Price:
$18.20
Log in for customized pricingproduct specifications
Type
Miniature
Weight
0.31
Number of Poles
1
Trip Curve
C Curve
Rated Current
3 A
Supply Voltage (Nominal)
277 VAC
product series specifications
Approvals: UL 489 File Number E355392 / UL 489A File Number E355393 / CSA C22.2 No.5 / IEC 60947-2
Warranty: 5-year limited warranty
Refer to Ex9 Series B1D, B1H, B1N, B1NQ Information Sheet for full specs:
product series features
- Breakers mount on standard 35 mm DIN rail
- B1NQ also provides flush and surface mount options with additional mounting clips
- Standard Interrupting ratings of 10 kA at 480Y/277 VAC and 10 kA at 125 VDC
- Suitable for branch circuit device protection
- Trip-free design - breaker cannot be defeated by holding the handle in the ON position
- Captive screws cannot be lost
- For use in applications for which UL 1077 or CSA C22.2 No.235 are also allowed
- Field installable shunt trip and auxiliary switch subsequent mounting
- Available with provisions for ring tongue terminals
- Module width of only 0.71 in (18 mm) per pole
- Contact position indicator (red/green)
- Possibility for locking the toggle in ON or OFF position Typical Applications Branch Circuit Protection
- Convenience receptacle circuits (internal/external)
- Motor control circuits
- Load circuits leaving the equipment (external)
- HVACR equipment: heating, ventilation, air conditioning, refrigeration (internal/external)
- PLC I/O points
- Power supplies
- Control instrumentation
- Relays
- UPS
- Power conditioners
more information & related documents
Series Description
The Ex9 Series-B (B1H/B1N/B1NQ/B1D) Miniature Circuit Breakers from NOARK Electric are UL 489 listed, mount on standard 35mm DIN rail, and are available in a complete range of amperages from 0.5A to 63A with trip curves to accommodate different applications. These miniature circuit breakers are suitable for branch circuit and supplementary protection.
Kele Description
CIRCUIT BREAKER, MINIATURE, 1P, C CURVE, 3A, 277 VAC
Manufacturer
Noark
B1NQ Datasheet
