WING-SPOT | RLE Technologies | Network & Wireless

Power: 3.6V AA lithium battery

Battery Life:

Up to 5 years when system spans full operating temperature range.

Up to 8 years at room temperatures up to 122°F (50°C)

Up to 12 years at room temperature

Shelf Life: 10 years in quiescent mode with battery installed

Transmission:

Interval: 10-20 seconds (random)

Frequency: Available in 868MHz and 900MHz configurations

Range: Up to 600ft line of sight

Leak Detection Input: Accepts up to 100ft (30.5m) of sensing cable, 50ft (15m) of sensing cable and one SD-Z spot detector, or 1 SD-Z1 spot detector

Compatibility: Compatible with all RLE sensing cables and the SD-Z and SD-Z1 spot detectors.

Sensor Response Time:< 20 seconds

Cable Break Detection: Yes

Cable Sensitivity: Configurable

Operating Environment:

Temperature: -13°F to 185°F (-25°C – 85°C)

Humidity: 0% to 90% RH (Non-condensing)

Altitude: -200 ft to 15,000 ft (-70m to 4572m) max

Mounting: Free standing, zip ties, screw and keyhole - spaced 2.5" (6.4cm), junction box - 2 screws spaced 3.28" (8.3cm)

Dimensions and Weight:

4.4" L x 2.5"W x 1.5”H (11.2cmL x 6.4cmW x 3.8cmH), 0.2lb (0.10kg)

Certifications and Standards: CE UL61010, CSA 22.2 #61010, IEC 61326-1, FCC 47CFR 15B, IC ICES-003, EN 61000-3-2, EN61000-3-3, ETSI EN 301 489-1, ETSI EN 301 489-3; FCC ID: X7J-A11072401: IC: 8975A-A11072401
