Supply Voltage:

AM3x: 18-30 VDC or 24 VAC 50/60 Hz

AMJRx: 10-30 VDC or 24 VAC 50/60 Hz

Communication Ports: RS-485 Port

Analog Input:

AM3x: 18 (16 universal + 2 analog)

AMJRx: 12 universal

Discrete Inputs: TTL to 24VDC

2, Pulse count frequency input Totalizing count input

Analog Output: AM3x: 4, 4-20mA (0-20mA) 8-bit resolution

Discrete Outputs:

AM3x: 8, Form A relay, 5A @ 120 VAC

AMJRx: 2, Open drain FET, 1A @ 24VDC

Processor:32-bit ARM

Signal LEDs:Power and communication

AM3x: 8

AMJRx: 2

Resolution:

AM3x: 0.1% reference up to 16-bit

AMJRx: 10-bit

Data Logging: Yes

Operating Temperature: -40° to 158°F (-40° to 70°C)

Operating Humidity: 5-90% RH non-condensing

Mounting: DIN rail

Dimensions:

AM3x: 3.94‚"H x 6.1"W x 2.36”D (100 x 155 x 60 mm)

AMJRx: 3.94"H x 2.76"W x 2.36”D (100 x 70 x 60 mm)

Weight:

AM3x: 2.0 lbs (0.91 Kg)

AMJRx: 1.5 lbs (0.68 Kg)

Approvals: CE, FCC, RoHs

Warranty: 1 year
