Supply Voltage: 11-28 VDC @ 1-5 mA

Connection: Terminal strip

Phone: Tone (DTMF) or pulse

Impedance: 600O

Alarm Input (AL): 2 alarm inputs

AL 1: Configurable NO or NC

AL 2: Configurable NO or NC

Alarm Out (LF): Phone line fail, 30 Volt triac

Dial Alert: LED indication during use

Microphone: Built-in

Controls:

12-key number pad

1 program and 1 stop button:

2 alarm buttons (AL-1, AL-2):

Memory: EEPROM, non-volatile

No. of Calls: 4 calls per alarm maximum or 2 pager calls maximum

Numbers / dial-out: 20 numbers maximum

Messages: 2, each using 2 segments

Message: 1, segment 1 & 2

Message: 2, segment 1 & 3

Segment 1: 14.5 seconds, activated for both alarms

Segment 2: 2.5 seconds, identifies alarm AL-1

Segment 3: 2.5 seconds, identifies alarm AL-1

Message Length:

Overall: 20 seconds for all segments

Dialing Attempts: Adjustable, 1-15

Message Repeats: Adjustable, 1-255

Time Between Repeats: 3 seconds

Dialer trigger delay: Adjustable, 1-255 seconds

Listen-in Function: Adjustable (enable/disable)

Listen-in Duration: Adjustable, 1-255 seconds

Acknowledge: First call or all calls (enable/disable)

Enclosure: NEMA 1

Operating Temperature: 32° to 122°F (0°to 50°C)

Dimensions: 4.25"H x 6.0"W x 1.4"D (10.5 x 15.0 x 3.5 cm)

Weight:0.5 lb (0.24 Kg)

Approvals: CE

Warranty: 1 year
