130 942 6103-E | Metz Connect | Network & Wireless
ETHERNET TERMINATOR MODULE
Brand:Metz Connect
MPN:130 942 6103-E
SKU:130 942 6103-E
List Price:
$56.47
Today's Price:
$29.36
Log in for customized pricingproduct specifications
Type
Module
product series specifications
Supply Voltage: 18 to 30 VDC @ 125 mA
Supply Watts:
Communication: Ethernet communications IEEE 802.3 10/100 Mbps data rate 10 BASE-T, 100 BASE-TX physical layer 100 m (max) CAT 5 cable length
LED Indication:
Power Green
Speed Green (100 Mbps)
Flash activity
Operating Temperature: 32° to 140°F (0° to 60°C)
Operating Humidity: 95% RH (non-condensing)
Dimensions: 0.92" x 2.9" x 4.29" (2.34 x 7.38 x 10.92 cm)
Weight: 0.77 lb (0.35 Kg)
Warranty: 1 year
product series features
- 5-port 10/100 Mbps Auto-negotiation ETHERNET ports
- Comprehensive front-panel diagnostic LEDs
- Supports Auto-MDI/MDI-X
- Full/half-duplex transfer modes for each port
- Wire speed reception and transmission
- Store-and-forward switching method
- Integrated address Look-Up Engine, supports 2K absolute MAC addresses
- Supports surge protection
- IEEE 802.3x flow control for fullduplex
- Supports DIN 35 rail
- Removable terminal block
more information & related documents
Series Description
The Wago 852 Series Ethernet Switch is a cost-effective solution to keep up with the constant demands for emerging IP-based industry communication needs. This easily configurable switch is ideally suited for small to medium-sized networks. The 852-111 has 5 ports with each port featuring auto-negotiation and auto MDI/MDI-X detection. Existing 10Mbps networks can now be upgraded effortlessly to higher speed 100Mbps Fast ETHERNET networks. The 852-111 5-port density can be used to create multiple segments to alleviate client congestion and provide dedicated bandwidth to each user node.
Kele Description
ETHERNET TERMINATOR MODULE
Manufacturer
Metz Connect
Related Documents
852 Ethernet Switch Installation Instructions
