ECB-PTU-208 | Distech Controls | Thermostats & Controllers

B-ASC programmable BTL-Listed room controller for terminal applications such as fan coil, chilled ceiling and others with universal power supply input (100-240VAC), 3 DI, 2 UI, 1 SI for NTC sensor, 3 DO (Fan, Relay 230 VAC), 1 DO (Electric Heater, Relay 255 VAC), 2 DO (Valves, Triac 24 VAC), 2 AO and 24 VAC power supply output. Support ECx-Light and ECx-Blind lights and blinds control modules.

Brand:Distech Controls

MPN:ECB-PTU-208

SKU:ECB-PTU-208

This product is retiring, try a replacement CDIB-PTU208XXX-00

List Price:

$-.--

Today's Price:

$-.--

catalog page

product series features

  • Flexible inputs and outputs support all industry-standard terminal unitary applications
  • Rugged hardware inputs and outputs eliminate the need for external protection equipment
  • Factory pre-loaded applications allow for out-of-the-box, energy efficient operation of standard terminal unitary equipment
  • End-to-end solution for support of Smart Room Control of HVAC equipment, lighting and sunblinds
  • Supports EC-gfxProgram, making Building Automation System programming effortless
  • Open-to-Wireless™ ready, supporting a wide variety of wireless sensors and switches and helping to reduce installation costs
  • eu.bac Certified Control Efficiency guarantees the highest level of performance of the products and systems
  • Controllers are BTL-listed and WSP-certified, which guarantee interoperability with other manufacturers’ BTL-listed controllers

more information & related documents

Series Description

The ECB-PTU Series controllers are microprocessor-based programmable controllers designed to control powered terminal units such as powered fan coil units, heat pumps units, and chilled beams. Each controller uses the BACnet® MS/TP LAN communication protocol and is BTL® -Listed as BACnet Application Specific Controllers (BASC) and WSP Certified. These controllers are optimized for ultra-low power consumption and can be operated as stand-alone units or as part of a networked system to suit any installation requirement.

Kele Description

B-ASC PGM BTL ROOM CTRLR FOR FCU, CC, 100-240VAC TO 24VAC, 3 DI, 2 UI, 1 SI, 3 DO, 1 DO, 2 DO, 2 AO

Manufacturer

Distech Controls
