VALUPOINT VP4-0630 PROGRAMMABLE I/O FOR BACNET MS/TP
Brand:Control Solutions
MPN:VP4-0630
SKU:VP4-0630
List Price:
$1,185.00
Today's Price:
$616.20
Log in for customized pricingproduct specifications
Power Supply
24 VAC, 24 VDC
Type
Universal
Communication Protocol
BACnet MS/TP
Number of Ports
6
product series specifications
Supply Voltage: 18-30 VDC @ 300 mA or 24 VAC @ 1.2 VA, 50/60 Hz
Communication Ports: RS-485
Baud Rate: BACnet MS/TP at 9600 to 76800 baud
Analog Input: 14 Universal Inputs 0-10 VDC, thermistor, digital, dry contact, pulse
Accuracy: 0.1% reference, up to 16-bit resolution, 10-bit fast scan mode
Non-volatile totalizing count inputs (10Hz on all channels, to 1kHz on 2 channels)
Analog Output: 3 Output 4-20mA (0-20mA), 8-bit resolution, 2-10VDC with 500 ohm load max.
Digital Outputs: 6 Outputs; Form A relay; 2A @ 120 VAC or 2A @ 30 VDC
Protocol: VP4-2330 BACnet MS/TP
Processor: ARM 32-bit; 64K Flash for User Program; Freely programmable; i.CanDrawIt® graphical programming
Data Logging: Yes
Operating Temperature: -40° to 185°F (-40° to 85°C)
Operating Humidity: 5-95% RH non-condensing
Mounting: DIN rail
Dimensions: 3.94" H x 4.13" W x 2.36"D (100 x 105 x 60mm)
Weight: 1.5 lbs (0.68 Kg)
Approvals: UL File# 312255, CE, RoHS
Warranty: 1 year
product series features
- BACnet MS/TP and Modbus RTU model options
- Implements B-ASC BACnet Standard Profile
- Freely programmable - i.CanDrawIt® graphical programming
- COV Subscription support
- BACnet client for interface to other slave devices
- Configurable object allocation, up to 200 objects (VP4-2330)
- Up to 320 Modbus Registers (VP4-2310)
more information & related documents
Series Description
The Control Solutions ValuPoint® Model VP4-2330 programmable I/O for BACnet MS/TP is a BACnet Application Specific Controller (B-ASC) that includes user programmable control, 14 analog/universal inputs, 3 analog outputs, and 6 relay outputs. VP4-2330 also includes a BACnet client for interface with other MS/TP devices. It includes an enhanced processor and expanded memory capacity along with a robust feature set. Model VP4-2310 supports Modbus RTU master or slave with 14 analog/univeral inputs, 3 analog outpus and 6 digital outputs.
Kele Description
VALUPOINT VP4-0630 PROGRAMMABLE I/O FOR BACNET MS/TP
Manufacturer
Control Solutions
Related Documents
VP4-23 Series Datasheet
