Supply Voltage: 125/277VAC, 50/60Hz.

Not Required to operate

Spring return count down timer

Operation: Manually Twist past mark time, On activation the contacts transfer from normal

Contact Output : SPST, 1-N.O. , SPDT or DPST 2-N.O.) per order

Contact Current:

Resistive 20A @125 VAC, 10A @277VAC

Ballast Do not use with Ballasts

Tungsten 7A Tungsten @125 VAC, (Compatable with CFL)

FAN 1 Hp @125 VAC, 2 Hp @240 VAC

Manual Override: Hold on some models

Special Functions: Decorator and full plastic faceplate, H model HOLD closed in the "ON" position

Timers:

FDxM 0-(5,15, 30, 60) minutes or

FDxH 0-(2, 4, 6, 12) hours

Operating Temperature: -40°C to 104°C (-40°F to 40°F)

Operating Humidity: 5% to 95% Non-condensing

Wiring Terminations: Terminals, 12 AWG max

Mounting: Vertical Decorator, Single gang 2.5" deep switch box (not included)

Color: Brushed metal with black letters

Enclosure Rating: NEMA 1

Dimensions: 1.6"W x 2.79"H x 1.2"D (4.0 x 7.1 x 3.0 cm), Knob 0.75" from faceplate

Weight: 0.4 lb. (0.18 Kg)

Approvals: CSA, UL File #E10694

Warranty: 1 year
