93504 | Capewell Aerial Systems | Lighting Controls
The Decora Series in-Wall Timer - 2 Hour - white and ivory decorator dial and knob included
Brand:Capewell Aerial Systems
MPN:93504
SKU:93504C
product specifications
Mount
Wall
Range
0 - 20 hr
Color
White
Supply Voltage (Nominal)
240 VAC
product series specifications
Supply Voltage: 125/277VAC, 50/60Hz; Not Required to operate; Spring return count down timer
Operation: Manually Twist past mark to desired time, On activation both contacts transfer from normal
Relay Output Configuration: 2-SPST, 1-N.O. and 1-N.C
Contact Current:
Resistive: 20A @125 VAC, 10A @277VAC
Ballast: Do not use with Ballasts
Tungsten: 7A Tungsten @125 VAC
FAN: 1 Hp @125 VAC
Manual Override: Hold on some models
Clock Accuracy: ± 5% of set time
Special Functions: 93351XC: HOLD closed in the "ON" position, Full Metal faceplate
Indicators: None
Timers: 0-(15, 30, 60, 120) minutes or 0-(4, 6, 12) hours
Operating Temperature: -40 to 120 ( -40 to 49)
Operating Humidity: 5% to 95% Non-condensing
Wiring Terminations: Terminals, 12 AWG
Mounting: Vertical, Single gang switch box (not included)
Color: Plastic plate in Ivory and White included
Enclosure Rating: NEMA 1
Dimensions: 1.8"W x 3.8"H x 1.2"D (4.5 x 9.7 x 3.1 cm) , Knob 0.75" from faceplate
Weight: 0.4 lb (0.18 Kg)
Approvals: UL Listed, File E13151
Warranty: 1 year
product series features
- White and ivory plates and knobs included
- Time range from minutes to 12 hours
- Two-wire design, for single-gang box
- 20 Amp resistive and 1HP capability
- Optional in.Hold in. models available
more information & related documents
Series Description
The Marktime 93000 Series wall box time switch is a spring wound, manually set time switch for the control of electrical current. Interchangeable with standard toggle switches to turn circuits either off or on at the end of a preset time period, the 93000 Series is ideally suited for new installations or retrofit projects.
Kele Description
K 0-120 MIN TIMER W/O HOLD
Manufacturer
Capewell Aerial Systems
Related Documents
93000 Series Timer Instructions
