Supply Voltage: 24 VDC, ±10%, 20 mA

Power Up Time: 90 second power warm up

Relay Type: SPDT

Relay Rating: 1 A @24V (AC/DC), 0.5 A @120VAC

Light Output: Adjustable 1-186 fc to initiate a 24VDC output

Technology: Passive Infra-Red (PIR) w/ Fresnel lens

Occupied Mode: Occupied-Auto ON w/Time Delay OFF

Coverage Pattern: Semi circle wedge 135 degrees, out to 43 ft.

Sensitivity: Adjustable High to Low

Override: Dip switch 5 (ON = Relay ON & light level CTRL disabled)

OFF Delay Time: Selectable, 30 second, to 30 minute

Indication: Red LED (ON w/ motion)

Mounting: Wall or Ceiling w/swivel bracket

Color: White

Operating Temperature: 32° to 98°F (0° to 36°C)

Operating Humidity: 10-95% RH non-condensing

Wiring: 8 Pig tails

Dimensions: 3.38"L x 3.35"W x 2.05"D, (8.6 x 8.5 x 5.2 cm)

Weight: 1.0 lb (0.46 Kg)

Warranty: 5 year
