Supply Voltage: 18 to 30 VDC

Accuracy: Overall ±12%, Operating Temp ±10%, Linearity ±2%, Repeatability ±0.5%

Analog Output: 4-20 mA @ 690

Sensor type: Blue-enhanced photo-diode

Range Adjust: Can be field adjusted with "MAS-CAL"

Indoor (MASI): 0-(50,100,200) fc = Selected per order

Outdoor (MASO): 0-(125,250,500) fc = Selected output per order

Atrium (MASA): 50-(500,1000,2000) fc = Selected output per order

Skylight (MASS): 100-(2500,5000,10000) fc = Selected output per order

Response Time Adjust: Instantaneous, 10 minutes or 20 minutes

Protective Lens: Non-polarized plastic

Indoor (MASI): Clear Fresnel lens

Outdoor (MASO): Clear flat lens

Atrium (MASA): Opaque dome

Skylight (MASS): Dark dome

Operating Temperature: -40° to 140°F (-40° to 60°C)

Operating Humidity: 10% to 95% Non-condensing

Wiring Terminations: 2 wire loop, 18 AWG pigtails

Mounting:

Indoor (MASI): Smooth back for ceiling down mounting w/double stick tape

Outdoor (MASO): 1/2" MNPT for Horizontal mount

Atrium (MASA): 1/2" MNPT for Vertical-up mount

Skylight (MASS): 1/2" MNPT for Vertical-up mount

Enclosure Rating:

NEMA 1- (Indoor, Atrium and Skylight)

NEMA 3R (Outdoor)

Dimensions:

Indoor (MASI): 1.5" x 1.5" x 1.7" (38 x 38 x 43 mm)

Outdoor (MASO): 1.4" x 1.4" x 2.4" (36 x 36 x 61 mm)

Atrium (MASA): 1.3" x 1.3" x 2.8" (33 x 33 x 71 mm)

Skylight (MASS): 1.3" x 1.3" x 2.8" (33 x 33 x 71 mm)

Weight: 0.13 lb (0.06 Kg)

Approvals: ETL, NEC Class 2, RoHS, Title 24

Warranty: 2 year
