0305RC22B11B4 | Rosemount | Level

Rosemount 305 Integral Manifold 2 Valve 316 Stainless Steel

Brand:Rosemount

MPN:0305RC22B11B4

SKU:0305RC22B11B4

List Price:

$-.--

Today's Price:

$-.--

product datasheet

installation instructions

Lead time of 0 days. Chat with Kele experts now

product specifications

Type

Accessory

product series specifications

Pressure and temperature ratings:

PTEE

6250 psi at -40 to 200 °F (431 bar at -40 to 93 °C) 4000 psi at 400 °F (276 bar at 204 °C)

Pressure and temperature ratings:

Graphite

6250 psi at -40 to 200 °F (431 bar at -40 to 93 °C) 1500 psi at 750 °F (103 bar at 399 °C)

Option CW1:

Temperature rating -67 °F (-55 °C)

Pressure and temperature ratings:

PTEE

6092 psi at -67 to 200 °F (420 bar at -55 to 93 °C) 4000 psi at 400 °F (276 bar at 204 °C)

Pressure and temperature ratings:

Graphite

6092 psi at -67 to 200 °F (420 bar at -55 to 93 °C) 1500 psi at 750 °F (103 bar at 399 °C)

Option BR6:

Temperature rating -76 °F (-60 °C)

Pressure and temperature ratings:

PTEE

6092 psi at -76 to 200 °F (420 bar at -60 to 93 °C) 4000 psi at 400 °F (276 bar at 204 °C)

Pressure and temperature ratings:

Graphite

6092 psi at -76 to 200 °F (420 bar at -55 to 93 °C) 1500 psi at 750 °F (103 bar at 399 °C)

product series features

Factory assembled, leak-tested, and calibrated
Full breadth offering including integral, in-line, and conventional styles
Integral design enables flangeless connection to instrument reducing weight, space, and leak points
Block-and-bleed, two-, three-, and five-valve configurations
Compact, lightweight design
Easy in-process calibration
Direct-mount capability
Available in NACE®-compliant materials of construction
Available with Pressure-Lock Valve

more information & related documents

Series Description

Emerson/Rosemount 0305 Series coplanar manifolds provide a leak checked, pressure-tested, single-point solution when assembled to Rosemount pressure transmitters. The coplanar platform reduces potential leak paths by 50 percent over conventional style process connections while also reducing overall connection system weight.

Kele Description

ROSEMOUNT 305 INTEGRAL MANIFOLD 2 VALVE 316SS

Manufacturer

Rosemount
