* product series image displayed
WD-1P | Kele | Leak
WATER DETECTOR SPOT LEAK
Brand:Kele
MPN:WD-1P
SKU:WD-1P
List Price:
$249.00
Today's Price:
$129.48
Log in for customized pricing24 in stock
product specifications
Application
Water
Indication
LED
Type
Tape
Supply Voltage (Nominal)
24 VAC, 24 VDC
product series specifications
- Supply Voltage:
- 11-27 VAC/VDC
- Supply Current:
- VDC:
- 10 mA typical,30 mA max (1-relay model)
- :
- 15 mA typcial, 60 mA max (2-relay model)
- VAC:
- 45 mA typical, 90 mA max (1-relay model)
- :
- 45 mA typical, 125 mA max (2-relay model)
- Relay Type:
- SPDT, 2 SPDT (DR only)
- Relay Rating:
- 1 A @ 24 VAC/VDC, 1/2 A @ 120 VAC
- Display:
- Green LED = Power
- :
- Red LED = Alarm
- Probe:
- Gold plated, 1.5‚Ä= adjustable
- Operating Temperature:
- 32° to 158‚Ñâ (0° to 70‚ÑÉ)
- Enclosure Rating:
- Plastic, NEMA 3R, weather resistant with adjustable legs
- Dimensions:
- 4.3"H X 3.75"W X 4.5"L (10.7 X 9.5 X 11.4 cm)
- Weight:
- 0.98 lb (6.44 Kg)
- Warranty:
- 1 year
product series features
- Weather resistant plastic enclosure
- Easy to install
- SPDT alarm contacts
- 11-27 VAC/DC(50/60 Hz)
- Reliable operation
- LEDs for power and alarm indication (green, red)
- Adjustable detection level
more information & related documents
Series Description
The Kele WD-1P water detector features gold-plated probes and microchip technology for dependable detection of conductive liquids. The Model WD-1P can be operated from 11-27 VAC/VDC. For application flexibility, SPDT contacts are provided to connect to a monitoring system. A height-adjustable, plastic, weatherproof enclosure is standard. A green LED visible outside the box indicates power. A red LED indicates water detected. The Model WD-1P is also available with an external tape style sensor, the Model WD-2PT.
Kele Description
WATER DETECTOR SPOT LEAK
Manufacturer
Kele
