Supply Voltage:

45, 135: 24-240 VAC, 50/60 Hz, @ 6.3 VA; 24 VDC @ 0.04 mA

270,450: 24-240 VAC, 50/60 Hz, @ 18 VA; 24 VDC @ 0.11 mA

Input Signal:0-10 VDC, 4-20 mA @ 100O or On/Off, Floating (24 to 240 VAC/VDC)

Feedback Signal: 0-10 VDC, 4-20 mA @ 800O

Maximum Shaft Size: 1/2" x 1/2" square (12 x 12 mm)

Minimum Shaft Length: 1" (2.5 cm)

Rotation: 95°

Manual Override: Crank included

Torque:

45 model: 45 in/lb (5 Nm)

135 model: 135 in/lb (15 Nm)

270 model: 270 in/lb (30 Nm)

450 model: 450 in/lb (50 Nm)

Runtime:

45, 135: 3/15/30/60 seconds adjustable

270, 450: 40/60/90/120 seconds adjustable

Spring Return: 10 seconds

Cable Length: 36" (1 m)

Operating Temperature: -40° to 122°F (-40° to 50°C)

Operating Humidity: 0 to 90% non-condensing

Enclosure Rating: Nema 4X (IP66)

Dimensions:

45, 135: 8.3" H x 3.7" W x 3.2" D (21 x 9.4 x 8.1 cm)

270, 450: 11.3" H x 5.9" W x 4.6" D (28.7 x 15 x 11.7 cm)

Weight: 45, 135: 8 lb (3.6 Kg); 270, 450: 23 lb (10.4 Kg)

Approvals: UL File #E340805, CSA

Warranty: 1 year
