Output:

Pulse: NPN open collector with square wave output, rated 60 V @ 50 mA max. Frequency: 3.2 to 200 Hz. Pulse Width: 2.5 msec ±25%

4-20 mA: 4 mA is 0 ft/s, 20 mA is 25 ft/s (7.6 m/s):

Repeatability: ±0.5% of full range

Linearity: ±1.0% of full range

Operating Temperature: -40° to 212°F (-40° to 100°C)

Media Compatibility: Water-based fluids

Enclosure Rating: NEMA 6P (IP67)

Housing Material: Brass or 316 stainless steel

Power Requirements: 10-35 VDC

Power Consumption: 40 mA (max.)

Pressure Limits: 400 psig (2758 kPa) @ 100°F (38°C), 325 psig (2241 kPa) @ 212°F (100°C)

Process Connection: 1-1/2" NPT male standard, 2" NPT male optional

Electrical Connection: 22 AWG shielded UL type PTLC rated 105°C, 20' (6.1 m) long with cable gland. Can be extended up to 2000' (609 m) with similar cable. Optional UL listed burial rated cable

Range: 1.2 to 25 ft/s (0.4 to 7.6 m/s)

Wetted Materials:

Body and Fitting: brass or 316 stainless steel (SS)

Fitting O-ring: FKM standard, silicone or Buna-N optional

Impeller: 316 SS

Shaft: tungsten carbide standard or 316 SS optional

Bearing: PTFE standard, carbon graphite optional

Approvals: CE

Weight: 3.0 lb (1.4 kg)

Warranty: 1 year
