Supply Voltage: 8-35 VDC @ 25 mA

Accuracy: ± 1% of flow rate

Output Signal: Models with standard frequency pulse, two-wire 4-20 mA @ 750O scaled pulse, or bi-directional (hot-tap models only)

Velocity Range: 0.3 to 20 fps (0.09 to 6.1 mps)

Wiring Terminations: Screw terminals

Conduit Connection: 1/2" FNPT

Configuration: A-SDI Programming software kit, includes 20' cable

Repeatability: ± 0.5%

Display: One line, eight-character 3/8" (.95 cm) LCD, annunciators for rate, total, input, output

Installation: Install in straight pipe section with a minimum distance of 10 pipe diameters upstream and 5 pipe diameters downstream to any bend, obstruction or transition

Mounting: 1" MNPT, mount in Thredolet or pipe saddle

Media Temperature Range: Maximum 300°F (149°C) for PEEK tip; 180°F (82°C) for PPS tip

Maximum Pressure: 1000 psig (6895 kPa) for stainless steel, 600 psig (4137 kPa) for brass

Pressure Drop: 0.5 psid (3.5 kPa), or less, at 10 fps velocity

Materials Of Construction: Polypropylene enclosure with Viton sealed acrylic cover, probe and sensor materials vary by model number (see ORDERING INFORMATION)

Operating Temperature: 14° to 150°F (-10° to 65°C)

Enclosure Rating: NEMA 4X

Warranty: 1 year
