HC16124P | Hoffman Enclosures | Enclosures
16 x 12 x 4 NEMA 1 Hinged Cover Enclosure with Perf Panel
Brand:Hoffman Enclosures
MPN:HC16124P
SKU:HC16124P
List Price:
$229.00
Today's Price:
$119.08
Log in for customized pricingproduct specifications
Material
Steel
Mount
Hinged
Type
Enclosure w/Perf
Enclosure Width
12 in
Enclosure Height
16 in
Enclosure Depth
4 in
product series features
- 16-gauge steel construction meets NEMA 1
- Removable doors with butt hinges
- Door hinge on left or right side
- Mounting holes on back of enclosure
- Easy operation of flush latch with a screwdriver or coin
- Various sizes of easily removable knockouts on all sides
- ANSI 61 gray polyester-powder finish inside and out over phosphatized surfaces
- Available with optional perf panel
- UL File #E27525
- CSA File #LL42184, RoHs
- One-year warranty
more information & related documents
Series Description
The HC series NEMA 1 hinge cover boxes serve as surface-mounted junction boxes or switch boxes. With the addition of a field-installed perforated subpanel, they can also house controls and instruments in areas that do not require oil-tight and dust-tight ratings.
Kele Description
NEMA 1 16X12X4 HINGED ENCL W/PERF
Manufacturer
Hoffman Enclosures
