LPCG757 | Arlington | Electrical Wiring Materials

List Price:

Today's Price:

product specifications

Accessory Type

Connector

Type

Accessory

Voltage Rating: 600 V

Current Rating: 20 A maximum

Wire Size: 24-12 AWG

Number Of Conductors: 2, 3, 5

Operating Temperature: 221°F (105°C) maximum

Strip Length: Strip to 11 mm

Dimensions:

221-412: 1.9 x 1.3 x 0.8 cm

221-413: 1.9 x 1.9 x 0.8 cm

221-415: 1.9 x 3.0 x 0.8 cm

Approvals: UL File #E69654

Warranty: 1 year

Connect any combination of solid, stranded, and flexible copper wires faster and more reliably
Minimize space consumption in the junction box by 40% compared to 222 Series
Visually inspect for proper strip length and complete wire insertion through its transparent housing
Operate comfortably and with lower operating forces by using familiar orange levers
Two test slots

Series Description

The Wago Compact Splicing Connectors for 2, 3, and 5 conductors.

Kele Description

LIQUIDTIGHT CORD

Manufacturer

Arlington
