Size: 1/2" - 3"

CV Range: 0.8 to 240 (2-way), 0.3 to 83 (3-way)

Body Pattern: Two-way, three-way mixing or diverting

Flow Characteristic: Two-way equal percentage, three-way linear

Leakage Rating: 0% for port A to AB; 2% maximum for port B to AB

Maximum Closeoff Pressure: 200 psi (1/2"-2"), 100 psi (2"- 3")

Materials Of Construction: Forged brass body with nickel plating, chrome plated (or stainless steel) ball, PTFE Teflon® seals, Tefzel® characterized disc, EPDM o-rings

Media Compatibility: Hot or chilled water, <60% glycol

Media Temperature Range: 0° to 250°F (-18° to 120°C)

Compatible Actuators: Non-spring return TR, LRB, NRB, ARB; spring return TF, LF, AF

Pressure Drop: Maximum differential pressure 30 psi

Pressure Rating: 600 psi (1/2" to 1-1/4"), 400 psi (1-1/4" to 3") for two-way; 600 psi (1/2" to 1"), 400 psi (1-1/4" to 2") for three-way

Approvals: CSA, CE

Warranty: 5 years
