51XBRFR24D | Edwards Signaling | Alarms & Indication
LED BEACON WITH HORN RED 24VDC
Brand:Edwards Signaling
MPN:51XBRFR24D
SKU:51XBRFR24D
List Price:
$1,209.00
Today's Price:
$628.68
Log in for customized pricingproduct specifications
Type
Beacon/Horn Light
Color
Red
Display
LED
Supply Voltage (Nominal)
24 VDC
product series specifications
Supply Voltage:
51XBRFx120A: 120 VAC, 50/60 Hz, 175 mA
51XBRFx24D: 24 VDC, 275 mA
Max. Off State Leakage Current: 10 mA
Surge (inrush / duration):
51XBRFx120A: 50 A / 260 µs
51XBRFx24D: 10 A / 120 µs
Colors: Amber, Blue, Green, Red, White
Flash Rate: 65 Flashes Per Minute (FPM)
Projected LED Life:148,000 hours
Horn Loudness: 85 dB @10', Synchronized with FPM.
Strobe Tube Life: 148,000 hours
Mounting: Direct surface mount, Mounted on 1/2 in. NPT conduit, Mounted on a 4 in. octagon box
Operating Temperature: -31°F to 150°F (-35°C to 66°C)
Dimensions: 7.38"H x 6"W (18.7cm x 15.2cm)
Weight: 2.14lbs (0.97 kg)
Approvals: UL file E340873
Warranty: 1.5 years
product series features
- LED light source with integrated horn
- Shatter-resistant double fresnel polycarbonate lens
- Five lens color options
- Immune to shock and vibration
- Cast metal base
- Suitable for indoor and outdoor applications
more information & related documents
Series Description
The Edwards Signaling 51XBR Series XTRA-BRITE™ LED beacons are combination visual and audible signaling devices, designed for indoor or outdoor applications. The integrated horn is synchronized with the flashing LED. The unit features a cast metal base that can be used as a junction box. The double fresnel lens is made of shatter-resistant polycarbonate and is designed to magnify the superbright LED.
Kele Description
LED BEACON WITH HORN RED 24VDC
Manufacturer
Edwards Signaling
Related Documents
51XBR Series Datasheet
