ASZ6.6 | Siemens Industry | Actuators & Dampers
STEM HEATING ELEMENT FOR SAX
Brand:Siemens Industry
MPN:ASZ6.6
SKU:ASZ6.6
product specifications
Type
Heat Element
product series specifications
- Input Impedance:
- :
- GXA161.1P, GNP191.1P 100kΩ @ 0/2-10VDC
- :
- GXA151.1P 100kΩ @ 0/2-10VDC, 500Ω @ 4-20ma
- Motor:
- Brushless DC
- Life Expectancy:
- 60,000 cycles, 100,000 full stroke cycles, 7,000,000 repositions (GNP)
- Rotation:
- 95°
- Manual Override:
- Manual crank (except GQD), Disengage button (GNP)
- Operating Temperature:
- -25° to 130°F (-32° to 55°C),
- :
- 0° to 122°F (-18° to 50°C) (GNP)
- Operating Humidity:
- 5 to 95% RH non-condensing
- Motor:
- Brushless DC
- Wiring:
- 3 ft (1.0 m), 18 AWG standard cable (.1U models), 3 ft (1.0 m), 18 AWG plenum cable (.1P models) See notes in Ordering Information for plenum option
- Conduit Connections:
- 1/2‚Ä= NSPT (GCA, GMA only)
- Resolution:
- 100 Steps
- Noise:
- <40 db @ 3' (1m)
- Input Impedance:
- 100kΩ @ 0/2-10VDC
- :
- 500Ω @ 4-20ma
- Approvals:
- UL File #E35198, CE, plenum rated
- Warranty:
- 2 years
product series features
- Self-centering shaft coupling
- Brushless DC motor technology
- Rugged, lightweight housings
more information & related documents
Series Description
The Siemens GMA and GCA Series direct-coupled spring-return actuators can control a complete range of HVAC spring-return damper applications. Each spring-return damper actuator is available in either 62 in-lb (7 Nm) torque, handling approximately 16 sq ft of damper area, or 160 in-lb (18 Nm) torque, handling approximately 40 sq ft of damper area. These damper actuators are available in all standard control signal types and offer a wide variety of options and accessories for building automation systems, BAS, applications.
Kele Description
STEM HEATING ELEMENT FOR SAX
Manufacturer
Siemens Industry
