602RF | Security Door Controls | Access Control
Power Supply 12/24 VDC 1 Amp
Brand:Security Door Controls
MPN:602RF
SKU:602RF
product specifications
Output
12/24 VDC
Type
Power Supply
product series specifications
- Supply Voltage:
- 115VAC, 50/60 Hz
- Battery:
- Charger = 13.5/27VDC, 500 mA
- Supply Current:
- 600 mA
- Output:
- 12/24 VDC, 1 amp
- Dimensions:
- 12‚Ä=W x 12‚Ä=H x 4‚Ä=D (30.5 x 30.5 x 10.2 cm)
- Weight:
- 8.8 lb (3.99 kg)
- Approvals:
- UL file #BP7341
- Warranty:
- 1 year
product series features
- Emergency release input
- Field selectable output 12/24VDC
- Input and output protection
- System status
- Low battery disconnect
more information & related documents
Series Description
The SDC 602RF power supply-charger devices are equipped with high performance transformers and highly reliable electronic components. Filtering and output voltage regulation provides protection and ensures the longevity of all system components. The user-friendly modular designs ensure versatility, interface capability and easy installation of electric locking devices, access controls and related safety equipment. The AC input is fuse protected and secondary DC output is protected by auto-reset poly fuse.
Kele Description
POWER SUPPLY 12/24 VDC 1 AMP
Manufacturer
Security Door Controls
